www.scheppach.com
GB
|
29
Vibration:
Vibration A
hv
(left/right) = 8.38 m/s²
Measurement uncertainty K
pA
= 1.5 m/s²
Keep the noise level and vibration to a minimum!
• Only use devices which are free of defects.
• Maintain and clean the device at regular intervals.
• Adapt your working methods to the device.
• Do not overload the device.
• Have the device checked if necessary.
•
• Wear gloves.
7. Unpacking
m ATTENTION!
The device and the packaging material are not
children’s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suocating!
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for transport
damage.
•
warranty period.
8. Before commissioning
Assembly
m Attention!
Always make sure the device is fully assembled
before commissioning!
Guide bar assembly (Fig. 3 - 9)
• Fit the lower push bar (3) as shown in Figures 3 + 4.
washers (G), two plastic star grip nuts (4) and two
locknuts (D).
• Connect the upper push bar (handle) (1) to the lower
push bar (3). To do so, use two plastic star grip nuts
and washers (G) (Fig. 5 + 6)
• Fit the draw wire holder (B) on the right side of the
steering bar as shown in Fig. 7.
• Fasten the cables to the push bar with the two cable
clamps (A). (Fig. 8 + 9)
- if the machine starts to vibrate unusually strongly
(inspect immediately)
Corrective maintenance instructions
-
specting or adjusting the machine and ensure that all
parts in motion have been stopped.
Disconnect the ignition cable and position the cable
away from the spark plug in order to prevent accidental
starting.
using only original spare parts. This ensures that the
safety of the machine is upheld.
6. Technical data
Type of engine Single-cylinder / 4-stroke
Displacement 212 cm³
-
mance
4.1 kW
Rotation speed 3400 min
-1
Fuel Unleaded petrol
Tank contents 3.6 l
Engine oil 10W 30 / SAE 30
Spark plug F7RTC
Oil/tank capacity 0.6 l
Depth setting +10 / -12
Working width of 400 mm
Number of blades 15
Blade Ø 165
Collection bag capacity 40L
Weight 28.2 kg
Technical changes reserved!
Information about noise level measured in accordance
with applicable standards:
Sound pressure L
pA
= 78.6 dB
Sound pressure L
wA
= 100.5 dB
Measurement uncertainty K
pA
= 1.9 dB
Wear hearing protection.
