Scheppach SG1200 User Manual

Please check the suitability for use of house hold
devices on the manufacturer information.
The machine may only be utilised for its intended
use.
Any other use is not intended. The user / operator,
not the manufacturer, is liable for resulting damages
or any type of injury resulting from any other use that
is not intended. Please ensure that this device was
not intended for commercial use. We do not accept
any warranty liability if the device is used for com-
mercial, manual, or industrial operations, or activities
similar to these.
4. Technical Data
Generator Inverter
Protection type IP23M
Continuous output P
rated
(S1) 1000 W
Max. output P
max
(S2/5 s) 1200 W
Nominal voltage U
rated
230 V~
Rated current I
rated
4,35 A
Frequency F
rated
50 Hz
Type drive motor 4 stroke air-cooled
Engine displacement 53,5 cm³
Max. power (motor) 2,1 kW/2,85 PS
Fuel: unleaded fuel
Tank capacity 4,2 l
Engine oil 0,25 l
(15W-40)
Use at 2/3 engine load approx.0,88 l/h
Weight 12,8 kg
Sound pressure level L
pA
74 dB(A)
Sound power level L
WA
95 dB(A)
Uncertainty K 1,07 dB (A)
Power factor cos ϕ 1
Performance class G1
Quality class B
Spark plug Torch A7RTC
Operating mode S1 (long use)
1. Introduction
Hersteller:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
We congratulate you on the purchase of your new
device. You have chosen a high quality product. The
instructions for use are part of the product. They
contain important information concerning safety, use
and disposal. Before using the product, please famil-
iarise yourself with all of the safety information and
instructions for use. Only use the unit as described
and for the specied applications. If you pass the
product on to anyone else, please ensure that you
also pass on all the documentation with it.
Important!
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating instructions and
safety information with due care.
We cannot accept any liability for damage or ac-
cidents which arise due to a failure to follow these
instructions and the safety information.
2. Device description (Fig. 1/7)
1. Handle
2. Fuel tank cap
3. Foot
4. Operating bulb
5. Oil check bulb
6. On/off switch
7. Earthing screw
8. 230 V~ socket
9. Choke lever
10. Starter grip
11. Air lter lid
12. Air lter
13. Oil ller plug
14. Low oil trip
15. Spark plug cap
16. Spark plug
17. Fuel tap
18. Fuel lter
A. Oil ller bottle
B. Handle
C. Screwdriver
D. Spark plug spanner
E. Socket wrench
F. Tool bag
3. Intended use
The generator is suitable for devices which use a
230 AC voltage source.
15/36
