27GB
Important! The work to change and align the saw
blade (7) must be carried out correctly.
8.11 Using the laser (Fig. 16,17)
To switch on: Move the ON/OFF switch of the laser
(35) to the “1” position. A laser line is projected onto
the material you wish to process, providing an exact
guide for the cut.
To switch off: Move the ON/OFF switch of the laser
(35) to the “0” position.
Replacing the battery: Switch off the laser (34). Re-
move the battery compartment cover (37). Remove
the batteries and replace with new batteries (3 x
LR44) Check that the battery terminals are positioned
correctly when inserting new batteries. Close the bat-
tery compartment (36) again.
8.12 Changing the speed (Fig. 2)
The saw has 2 speed ranges:
langsam schnell
vitesse lente vitesse rapide
slow fast
Pomalu rychle
Pomalý rýchly
Počasnega
hitrega
lassú gyors
бавно бързо
Nopea hidas
To operate the saw at a speed of 3200 rpm (metal),
set the switch (42) to position I.
To operate the saw at a speed of 4500 rpm (wood),
set the switch (42) to position II.
9. Transport (Fig. 1,2)
Tighten the set screw (26) in order to lock the rotary
table (16)
Activate the release lever (3), press the machine head
(5) downwards and secure with the safety pin (24).
The saw is now locked in its bottom position.
Fix the saw’s drag function with the locking screw for
drag guide (23) in rear position.
Carry the equipment by the xed saw table (17).
When reassembling the equipment proceed as de-
scribed under section 7.1.
10. Maintenance
m Warning! Prior to any adjustment, maintenance or
service work disconnect the mains power plug!
General maintenance measures
Wipe chips and dust off the machine from time to time
using a cloth. In order to extend the service life of the
tool, oil the rotary parts once monthly. Do not oil the
motor.
When cleaning the plastic do not use corrosive products.
Brush inspection
Check the carbon brushes after the rst 50 operating
hours with a new machine, or when new brushes have
been tted. After carrying out the rst check, repeat the
check every 10 operating hours.
If the carbon is worn to a length of 6 mm, or if the spring
or contact wire are burned or damaged, it is necessary
to replace both brushes. If the brushes are found to be
usable following removal, it is possible to reinstall them.
11. Storage
Store the device and its accessories in a dark, dry and
frost-proof place that is inaccessible to children. The
optimum storage temperature is between 5 and 30˚C.
Store the electrical tool in its original packaging.
Cover the electrical tool in order to protect it from dust
and moisture.
Store the operating manual with the electrical tool.
12. Electrical connection
The electrical motor installed is connected and ready
for operation. The connection complies with the ap-
plicable VDE and DIN provisions.
The customer‘s mains connection as well as the
extension cable used must also comply with these
regulations.
Important information
In the event of an overloading the motor will switch itself
off. After a cool-down period (time varies) the motor can
be switched back on again.
Damaged electrical connection cable
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
Passage points, where connection cables are passed
through windows or doors.
Kinks where the connection cable has been improperly
fastened or routed.
Places where the connection cables have been cut
due to being driven over.
Insulation damage due to being ripped out of the wall
outlet.
Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage regu-
larly. Make sure that the connection cable does not hang
on the power network during the inspection.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with the marking „H05VV-F“.
The printing of the type designation on the connection
cable is mandatory.
AC motor
The mains voltage must be 230 V~
Extension cables up to 25 m long must have a cross-
section of 1.5 mm2.
Connections and repairs of electrical equipment may
only be carried out by an electrician.
Please provide the following information in the event of
any enquiries:
Type of current for the motor
Machine data - type plate
