Position a 125mm diameter round disc on the
spring-loaded adjusting ring of the pressure
chamber.
Tighten by turning the handle clockwise, so that
the chamber and clamping handles are parallel
(curved red arrow).
Align the clamping frame over the material so
that the three clips slip under the bevel of the
locking device on the sides of the chamber.
