1 RCA Inputs. Connect Mani’s RCA inputs to your
turntable, using quality shielded cables.
2 RCA Outputs. Connect Mani’s RCA outputs to
your preamp or headphone amp.
3 Ground. Connect the turntable ground to Mani’s
ground input, if you have hum problems.
4 Power Input. Connect the supplied 16VAC wall-
wart to the Mani with the attached cord.
5 Power Switch. Turn it on and enjoy your music!
18.200101
OUT IN
GAIN 2
GAIN 1
LOAD
L H
47
47K
47
47K
L H
H
L
H
L
12
3
4
5
CONNECTIONS
VERY IMPORTANT: Turn on Mani FIRST, before
any other components like power amps, or else
you may get some very loud pops through your
system. Turn Mani off AFTER turning off power
amps, for the same reason. Also, DO NOT change
gain switch settings with Mani on. Turn your
whole system off, change gain, and then observe
the same turn-on sequence.
