1 RCA inputs. Connect up to 4 inputs to
Saga using RCA cables. The inputs are
conveniently numbered “1” to “4” to match
the front panel indicators. Tricky, huh?
2 XLR outputs. XLR balanced outputs?
Yes. These are real XLR balanced
differential outputs, so you can connect to
downstream balanced power amps (or run
a couple of Vidars or Gjallarhorns in mono,
hint hint!) using XLR cables.
3 RCA outputs. No, we are not insane, so
you get single-ended RCA outputs here as
well. Connect to any of your single-ended
gear using RCA cables.
4 Power switch. Up is on, down is off.
Simple as that. But it won’t work at all
unless you proceed to (5) below.
5 AC inlet. Connect the output of the
special 24/6VAC wall-wart here. You’ll
need this wall adapter; as far as we know,
there are no other 24/6 dual AC wall-warts
out there. Lost it? We sell replacements on
the site, and cheap!
Note: it may make you feel better to refer to the
wall-wart as an “external linear power supply,” but
that’s awfully fancy for a simple preamp, isn’t it?
CONNECTIONS
1
3
5
2
4
1 2 3 4
1
1 1
