Schlage Connect Smart Deadbolt User Manual

3
step
Install the touchscreen.
Route the cable through the door BELOW the bolt. Align the
tailpiece as shown and push the touchscreen onto the door.
Is it hard to install the touchscreen?
Is the tailpiece not installing correctly?
If the hole through your door seems
too small, you may need to remove the
spacer. See the online instructions.
The bump on the
tailpiece aligns
with the slot in the
bolt.

Schlage Connect Smart Deadbolt Specifications

General

Lock Type	Deadbolt
Keypad	Yes
Keyless Entry	Yes
Power Source	4 AA batteries
Backup Power	No
User Codes	Up to 30
Operating Temperature	-40°F to 140°F (-40°C to 60°C)
ANSI Grade	Grade 1
Keyway	Schlage C Keyway
Auto-Lock	Yes
Connectivity	Z-Wave
Finish Options	Satin Nickel, Matte Black
Alarm	Yes
Voice Assistant Compatibility	Amazon Alexa
Smart Home Compatibility	Z-Wave systems
Door Thickness	1-3/8" to 1-3/4"
Backset	2-3/4"
Installation	DIY
Warranty	Limited lifetime mechanical
Alarm Technology	Built-in alarm
