Schlage GWE - Power Supply

Schlage GWE
15 pages
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
11
Tx+
Tx-
Rx+
Rx-
GND
+
Power Supply
UL294 or ULCS318/
ULCS319 Listed power limited
250mA 12 or 24 V DC
Access Control Panel
Shielded
Remove
jumper
4 Wire Diagram
Power Supply
UL294 Listed power limited
250mA 12 or 24 V DC
