L Service Manual
136
Ordering Procedures
To order Schlage products, descriptive data should be in the same sequence as shown:
1) Line Item: Line item number
2) Qty: Quantity
3) Product: Complete lock product or part number
4) Outside DES: Outside design code
5) Outside FIN: Outside finish code
6) Inside DES: Inside design code: Leave blank if same as outside design code.
7) Inside FIN: Inside finish code: Leave blank if same as outside finish code.
8) Hand: Hand of door: Only one hand allowed per line item. Example: RH=Right Hand, LH=Left Hand, RR=Right
Reverse, LR=Left Reverse
9) Latch: Latch: Leave blank for standard or specify part number if non-standard latch is required. LLL=Less Latch.
10) Strike: Strike: Leave blank for standard or specify part number if non-standard strike is required. LLL=Less Strike.
11) DR THK: Door thickness: Enter door thickness if non-standard. Example: 138=1
³⁄₈”, 214=2¹⁄₄”, 212=2¹⁄₂”.
12) EXT: Extension: Enter one of the following when doors 2” thick or greater are specified: EE=Extended Equally,
EI=Extended Inside, EO=Extended Outside, ED=Extended Differently. EI or EO assumes the latch with be
centered on 1
³⁄₄” door, to which material has been added.
13) DIM: Dimension: Enter dimension for non-standard strike lip length and mortise cylinder or blocking ring length.
012 = ¹⁄₈” 118 = 1¹⁄₈”
018 = ³⁄₁₆” 114 = 1¹⁄₄”
025 = ¹⁄₄” 138 = 1³⁄₈”
031 = ⁵⁄₁₆” 112 = 1¹⁄₂”
037 = ³⁄₈” 158 = 1⁵⁄₈”
050 = ¹⁄₂” 134 = 1³⁄₄”
078 = ⁷⁄₈” 200 = 2”
100 = 1” 400 = 4”
14) Additional Details: Enter detail for keying information and for special requirements.
15) Examples:
Line
Item
Qty Product
Outside Inside
Hand Latch Strike
DR
THK
EXT DIM Additional Details
DES FIN DES FIN
1 2 3 4 5 6 7 8 9 10 11 12 13 14
LINE
ITEM QTY PRODUCT
OUTSIDE INSIDE
HAND LATCH STRIKE
DR
THK EXT DIM ADDITIONAL
DETAILS
DES FIN DES FIN
One mortise cylinder, 1¹⁄₄” long, which will operate a Von Duprin exit device.
17 1 20-001 626 114
One hotel function L-Series lock with 17B trim in 625 for left hand door.
18 1 L9485P 17B 625 LH 114
Five replacement inside L escutcheons with “EZ” turn, in satin stainless steel, to be used with 06 lever on 1³⁄₄” doors.
19 5 09-633 06L 630 134 w/EZ turn per
XL11-800
