5.2 Adjustable applications
SRB-E-204ST
Rotary knob
position
Reset button (detection
of the trailing edge)
Cross-wire
monitoring active
Sensor Input / Sensor
configuration
Monitoring of sensor channels
for synchronisation (< 5 sec.)
1 Yes Yes 1 – 4 NC / NC Yes
2 Yes Yes 1 – 4 NC / NC No
3 Yes No 1 – 4 NC / NC Yes
4 Yes No 1 – 4 NC / NC No
5 Yes Yes 1 – 4 NC / NO Yes
6 Autostart Yes 1 – 4 NC / NO No
7 Autostart Yes 1 – 4 NC / NC Ye s
8 Autostart Yes 1 – 4 NC / NC No
9 Autostart No 1 – 4 NC / NC Yes
10 Autostart No 1 – 4 NC / NC No
11 Yes
Yes
Yes
No
No
1
2
3
4
NC / NC No
12
Autostart
Yes
Yes
No
No
1
2
3
4
NC / NC No
13 Yes Yes
Yes
Yes
No
1
2
3
4
NC / NC No
14
Autostart
Yes
Yes
Yes
No
1
2
3
4
NC / NC No
C Configuration mode
SRB-E-204PE
Rotary knob
position
Reset button (detection
of the trailing edge)
Cross-wire
monitoring active
Sensor Input / Sensor
configuration
Monitoring of sensor channels
for synchronisation (< 5 sec.)
1 --- Yes 1 – 4 NC / NC Yes
2 --- Yes 1 – 4 NC / NC No
3 --- No 1 – 4 NC / NC Yes
4 --- No 1 – 4 NC / NC No
5 --- Yes 1 – 4 NC / NO Yes
6 --- Yes 1 – 4 NC / NO No
7 ---
Yes
No
No
No
1
2
3
4
NC / NC No
8 ---
Yes
Yes
No
No
1
2
3
4
NC / NC No
9 ---
Yes
Yes
Yes
No
1
2
3
4
NC / NC No
C Configuration mode
