Operating instructions
Safety-monitoring module
SRB-E-204ST / SRB-E-204PE
EN
5.3 Changing setting or application
Description / procedure Rotary (mode) switch System response LED indications
RUN In 1 In 2 Out
Factory setting Position 1 Ready for application 1 - - - -
Switch operating voltage on Position 1 Without connected sensors! Lights up - - -
Turn to position C Application 1 is deleted Lights up Flashes Flashes Flashes
Setting cycle active
Application 1 is deleted - - - -
No valid application stored Flashes - - -
SRB-E ready for new applications
Select new application Select desired application (1-11) New application will be loaded Lights up - - -
Setting cycle active
Lights up Lights up - -
Lights up Lights up Lights up -
Lights up Lights up Lights up Lights up
Ready for operation The desired application is configured Adopt new application Lights up - - -
Switch off operating voltage and connect wires according to selected application -> SRB-E... ready for operation
