STEUEREINHEIT AIRBASIC 2 –GEBRAUCHSANWEISUNGEN
AIRBASIC 2 CONTROLLER – USER MANUAL
39
The table below contains all the available parameters with their respective symbol, descriptions, units of
measurement, possible values and default values. For more detailed description, see "Parameter descriptions"
on page 17. The parameters from P01 and P04 are shown only using pressure transducer.
Parameters
Param.
symbol
Description Unit Range
Default
Profile
0
Default
Profile
1
P01 High plant pressure alarm bar 15,0 –(P02+0,5) 11,0 11,0
P02 Unload pressure bar
(P01-0,2)-
(P03+0,2)
10.0 10.0
P03 Load pressure bar
(P02-2) − +3.0
9.0 9.0
P04
Offset for pressure transducer
calibration
bar -2,0 – +2,0 0,0 0,0
P05 Max probe temperature °C 130 – ( P06+2) 120 120
P06
High oil temperature alarm
threshold
°C
(P05-2)−(P07+2)
110 110
P07
High oil temperature pre-alarm
threshold
°C
(P06-2)−(P08+2)
105 105
P08
Low oil temperature alarm
threshold
°C
(P07-2) − -10
-5 -5
P09
Offset for oil temperature probe
calibration
*C
-10 − +10
0 0
P10
Ventilator switch on temperature
threshold
°C
(P05-2) − +30
70 70
P11
Ventilator switch on temperature
hysteresis
°C
+5 − +15
5 5
P12 Star time s
2 − 10
5 5
P13 Star-delta switching time ms
10 − 50
20 20
P14 Launch time s
1 − 5
1 1
P15 Unload time min
0 − 10
3 0
P16 Delay time for switch off s 1 - 60 15 15
P17 Delay time for restarting s 1 - 60 15 15
P18 Max restarts per hour / 1 - 60 20 60
