OPERATION
FX-209 07/19 Operation Section 4-48
© 2019 Alamo Group Inc.
OPERATION
Blade Bolts won’t stay Bolts not tightened. Tighten bolts to 600 ft. lbs.
tight Bolt hole elongated or oversized Replace Bushing or Blade Carrier.
Locknut worn out. Replace Locknut.
Tongue bending or Improper Drawbar. Add attaching Plate to all 3-Point
binding in turns drawbars. See section on attaching
mower to tractor.
Torque limiter slipping Excessive load Machine is overloaded, reduce
excessively ground speed and material intake
Improper Adjustment Adjust Springs
Friction plates worn Replace plates
Oil on friction plates Replace plates
Oil leaking from hydraulic Oil leaking past piston ring, On main lift cylinder use depth stop
cylinder vent a small amount of leakage is to carry. If leakage is excessive
normal replace piston rings.
Cylinder wall scored or pitted Replace cylinder
To Next Page
