USING AN EXTENSION CORD
The use of an extension cord is not
recommended. If you must use an
extension cord, follow these guidelines:
• Pins on plug of extension cord must be the
same number, size, and shape as those of
plug on charger.
• Ensure that the extension cord is properly
wired and in good electrical condition.
• Wire size must be large enough for the AC
ampere rating of charger, as specied below:
Length of cord (feet)
25 50 100 150
AWG* size of cord
18 18 18 16
*AWG-American Wire Gauge
OPERATING INSTRUCTIONS
WARNING: A spark near battery may cause
a battery explosion.
IMPORTANT: Do not start the vehicle with
the charger connected to the AC outlet, or it
could result in damage to the charger
NOTE: This charger is equipped with an
auto-start feature. Current will not be
supplied to the battery clamps until a battery
is properly connected. The clamps will not
spark if touched together.
CHARGING A BATTERY IN THE VEHICLE
1. Turn off all the vehicle’s accessories.
2. Keep the hood open.
3. Clean the battery terminals.
4. Place the charger on a dry, non-
ammable surface.
5. Lay the AC/DC cables away from any
fan blades, belts, pulleys and other
moving parts.
6. For a negative-ground vehicle (as in
most vehicles), connect the charger’s
POSITIVE (RED) clamp to the POSITIVE
(POS, P, +) battery post. Next, connect
the charger’s NEGATIVE (BLACK) clamp
to the vehicle chassis or engine block,
away from the battery.
7. For a positive-ground vehicle, connect the
charger’s NEGATIVE (BLACK) clamp to the
NEGATIVE (NEG, N, -) battery post. Next,
connect the charger’s POSITIVE (RED)
clamp to the vehicle chassis or engine
block away from the battery. NEVER
connect any clamps to the carburetor, fuel
lines or sheet-metal body parts.
8. Connect the charger to an electrical outlet.
9. Select the battery type and the charge rate.
10. When charging is complete, disconnect
the charger from the AC power, remove
the clamps from the vehicle’s chassis,
and then remove the clamp from the
battery terminal.
CHARGING A BATTERY OUTSIDE
OF THE VEHICLE
1. Place battery in a well-ventilated area.
2. Clean the battery terminals.
3. Connect a 24-inch long, 6-gauge (AWG)
insulated battery cable to the NEGATIVE
(NEG, N, -) battery post (i.e., jumper
cable) (not provided).
4. Connect the POSITIVE (RED) clamp to
the POSITIVE (POS, P, +) battery post.
5. Position yourself and the “negative post
extension” cable as far away from the
battery as possible, and connect the
NEGATIVE (BLACK) clamp to the cable’s
free end.
6. Connect the charger to the electrical outlet.
7. Select the battery type and the charge rate.
8. When charging is complete, disconnect
the charger from the AC power,
disconnect the negative clamp, and nally
the positive clamp.
9. A marine (boat) battery must be removed
and charged on shore.
CHARGE RATE
The charger will automatically adjust the
charging current, based on battery size, in
order to charge the battery completely,
efciently and safely.
AUTOMATIC CHARGING MODE
When an Automatic Charge is performed,
the charger switches to the maintain mode
(see below) automatically after the battery is
charged.
ABORTED CHARGE
If charging cannot be completed normally,
charging will abort. When charging aborts,
the charger’s output is shut off and the
CHARGING
(yellow) LED will ash.
The digital display will show an error code
(see the Troubleshooting section for a
description of the error codes). To reset
after an aborted charge, unplug the charger
from the AC outlet, wait a few moments and
then plug it back in.
