General
01.00 | Electric gripper EGP with safety functions | System description | en | 1381596
5
1.3 Components for the system setup
NOTE
For monitoring of redundant sensor signals, SCHUNK recommends
inductive proximity switches IN 40.
The following components are required for the system setup:
• Electric gripper EGP
• 4 x sensors
– e.g. inductive proximity switches
IN 40/S-M8, SCHUNK Id-No. 0301474
• Sensor bracket (2x)
–SCHUNK Id-No. 9700901
• Spacer sleeve for adjusting the sensor position
–SCHUNK Id-No. 5509536
• Sensor distributor
• Safety control system
–e.g. PILZ PNOZmulti or LTI SMC1-Z10
