Nano43
Calibration F
x
/ F
y
[N]
F
z
[N]
M
x
/ M
y
[Nmm]
M
z
[Nmm]
F
x
/ F
y
[N]
F
z
[N]
M
x
/ M
y
[Nmm]
M
z
[Nmm]
SI-9-0.125 9 9 125 125 1/512 1/512 1/40 1/40
SI-18-0.25 18 18 250 250 1/256 1/256 1/20 1/20
SI-36-0.5 36 36 500 500 1/128 1/128 1/10 1/10
Ranges of measurement FTD, FTN, FTW, FTE resolution
