Assembly
5 Assembly
5.1 Assembly and connection
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
• Before starting any work on the product: Switch off the power
supply and secure against restarting.
• Make sure, that no residual energy remains in the system.
1. Commission the associated interface,
Applicable documents [}5].
2. Check the evenness of the mounting surface,
Mechanical connection [}47].
3. Screw the product to the machine/system,
Mechanical connection [}47].
✓ If necessary, use appropriate connection elements (adapter
plates).
4. Connect and lay the sensor cable,
Electrical connection [}52].
5.2 Connections
5.2.1 Mechanical connection
Evenness of the
mounting surface
The values apply to the whole mounting surface to which the
product is mounted.
Requirements for evenness of the mounting surface (Dimensions in mm)
Edge length Permissible unevenness
< 100 < 0.02
> 100 < 0.05
