Assembly
The adapter plate must meet the following requirements:
• For precise assembly, the adapter plate requires precisely
measured bore holes for the mounting screws, the alignment
pins and the centering collar
• The bore holes in the adapter plate should not all be aligned
centrally. A larger bolt pitch circle ensures more accurate
measured values because less bending occurs in the plate.
• To guarantee the necessary tightening torque, the adapter plate
must have a sufficient height.
• The mounting screws must not be too long in order to prevent
damage to the internal electronics of the force-torque-sensor.
The adapter plate must have an even and stable surface running
parallel to the force-torque-sensor to prevent distortion during
operation.
The catalog data sheet contains detailed information and precise
manufacturing instructions for possible adapter plate design,
Applicable documents [}5].
CAUTION
Risk of damage to the sensor!
The internal electronics can get damaged if the interface plate is
removed.
• Do not touch the internal electronics.
• Protect internal electronics from contamination.
CAUTION
Risk of damage to the sensor!
The sensor can get damaged if the specified range of
measurement is exceeded.
• Only mount the sensor if the corresponding interface has
been put into operation to check the saturation.
• If an error occurs during assembly, wait until the error
disappears.
4703.00 | FT | Assembly and Operating Manual | en | 389582
