Technical Data
10 QM.UC.00002-R3.0 |en
Technical Data
Type
FORCE-1.DIN / KEH.P / KEH.R
Mains voltage 200 – 230 – 400 – 460 (VAC)
Frequency 50Hz / 60Hz
Phases 2 + PE
Rated current 32 A
Rated short circuit current 6 kA
Breaking current of the fuse
for
the auxiliary cir-cuit
500 mA at 500 V AC
IP rating IP20 regarding the control unit
IP rating of the equipment in which it is installed:
at customer’s care
Activation time >0.3s at cycle 3; < 8s at cycle 8
Activation change 1 (de-) magnetization - max. every 3 min.
Weight ~ 2 kg
Ambient temperature 5° - 55° C
Ambient conditions Operation in dry interiors
with a relative air humidity of approx. 5 - 15%
Protect product from caustic vapors and excessive heat.
5
