Initial commissioning and normal operation
18 QM.UC.00002-R3.0 |en
Normal operation
To guarantee a proper functioning of the control unit, please carry
out the following steps:
1 Ensure that the magnetic chuck is not magnetized, by means
of the steel tip of a screw driver.
2 Apply voltage to the control unit.
3 Place the workpiece onto the magnetic chuck.
WARNING
Danger due to suspended loads.
If this work requires the use of lifting equipment, cranes etc.,
please keep the respective safe distances!
4 Carry out a magnetization cycle on the chuck.
REMARK
For a proper connection of the external control signals, please
refer to the specific wiring diagram the control unit is supplied
with.
5 Make sure that the workpiece remains clamped onto the
magnetic chuck.
CAUTION
Risk of injury due to workpieces coming undone due to a faulty
display of the magnetic clamping system.
• Ensure that the workpiece is properly clamped on the magnetic
chuck (for example with the steel tip of a screwdriver), by tak-
ing the suitable safety precautions!
6 The workpiece is now ready to be machined.
7 Carry out the demagnetization of the chuck.
REMARK
For a proper connection of the external control signals, please
refer to the specific wiring diagram the control unit is supplied
with.
