F
On/off
~68 °F
Fan speed 1/2/3
On/off
Fan speed 1/2/3
Remote control - on/off, fan speed and heating steps
Heat step
Electric: Half/full power
Water: On/off (1 LED)
Control panel - Unit without heating
Control panel - Unit with electrical heating or
water heating
1
3
2
Functional test
Functional test is started using the remote control.
Push and in
5 seconds
Fan and heatings steps are tested in 10-second
intervals which is indicated by lighted LEDs.
When the test is completed, all LEDs will flash for 30
seconds.
Temperature control
If the temperature exceeds 122 °F, the fan runs at
full speed for 2 minutes to vent out the heat, if the
temperature rises above 122 °F again during the
following 5 minutes overheating alarm is deployed.
The red LEDs flash and all the buttons are locked.
1. Disconnect the power supply with the isolator
switch.
2. Determine the cause of overheating and rectify
the fault.
3. Reconnect the unit.
