Schwank Select12 Series - Technical Specification

schwankgroup.com/schwankair
3 Electrical heat - (IP20)
Model Output (kW) Airflow*
1
(CFM)
Sound
power*
2
(dB(A))
Sound
Pressure
(dB(A))
FLA (full load
amperage)*
3
(A)
Motor
power
(W)
Amperage
motor
(A)
Voltage (V)
Amperage (A)
(heat)
Weight (lb)
AC-TE36-20 4/7 1150 73 55 21 135 0.86 208V3~/19 57
AC-TE60-20 7/10 1600 72 54 29 147 0.94 208V3~/28 82
AC-TE72-20 8/13 2250 75 57 39 270 1.71 208V3~/36 112
AC-TE36-48 4/8 1150 73 55 11 135 0.86 480V3~/10 57
AC-TE60-48 6/12 1600 72 54 16 147 0.94 480V3~/15 82
AC-TE72-48 8/16 2250 75 57 21 270 1.71 480V3~/20 112
AC-TE36-60 4/8 1150 73 55 9 135 0.86 600V3~/8 57
AC-TE60-60 6/12 1600 72 54 13 147 0.94 600V3~/12 82
AC-TE72-60 8/16 2250 75 57 17 270 1.71 600V3~/16 112
1 Ambient, no heat - (IP21)
Model Output
(MBH)
Airflow*
1
(CFM)
Sound power*
2
(dB(A))
Sound Pressure
(dB(A))
Motor
power (W)
Voltage
motor (V)
Amperage
motor (A)
Weight (lb)
AC-TA36-23 0 1150 73 55 135 208V~ 0.86 49
AC-TA60-23 0 1600 72 54 147 208V~ 0.94 71
AC-TA72-23 0 2250 75 57 270 208V~ 0.72 93
Model Output*4
(MBH)
Airflow*1
(CFM)
Sound
power*2
(dB(A))
Sound Pressure
(dB(A))
Motor
power
(W)
Voltage
motor
(V)
Amperage
motor
(A)
Water
volume
(US gal)
Weight
(lb)
AC-TW36-23 27 1050 72 54 109 208V~ 0.71 0.34 57
AC-TW60-23 48 1550 72 54 135 208V~ 0.86 0.55 79
AC-TW72-23 65 2150 74 56 218 208V~ 1.42 0.71 106
2 Water heat - (IP21)
1. Highest airflow at 3 fan speed.
2. Values shown are for total sound power levels for Installation Type A: free inlet, free outlet.
3. The Sound power level ratings shown are in decibels, referred to 10-12 watts, calculated per AMCA
Standard 301.
4. FLA: total amperage for motor and heat.
5. Applicable at water temperature 140/104F, air temperature, in +64F.
Above table is valid for 208V/1ph/60Hz. Also approved for 230V/1ph/60Hz. Product performance for
230V/1ph/60Hz will differ from stated data.
Protection class for units with electrical heating: (TE) IP20.
Protection class for units without electric heating and units with water heating: (TW) IP21.
Technical Specification
