Schwank Select12 Series - Page 5

schwankgroup.com/schwankair
Valve (3/4
")
Valve (3/4 ")
G
L
M
K
JO
G
Valve (3/4 ")
Valve (3/4 ")
E / C / A
G
KN
R H
QI
P
J
O
F / D / B
Valve (3/4"),
outside thread
L = 6.6 ft
A/W
Valve (3/4
")
Valve (3/4 ")
L KG G
E
Ref (inch) Model
A 81.40 AC-TA72-23
AC-TE72-20(48)(60)
AC-TW72-23
B 80.5 AC-TA72-23
AC-TE72-20(48)(60)
AC-TW72-23
C 62.1 AC-TA60-23
AC-TE60-20(48)(60)
AC-TW60-23
Ref (inch) Model
P 2 All Models
Q 1.65 All Models
R 0.39 All Models
Ref (inch) Model
D 61.2 AC-TA60-23
AC-TE60-20(48)(60)
AC-TW60-23
E 42 AC-TA36-23
AC-TE36-20(48)(60)
AC-TW36-23
F 41.1 AC-TA36-23
AC-TE36-20(48)(60)
AC-TW36-23
Ref (inch) Model
G 81.40 All Models
H 18 All Models
I 10 All Models
J 8.22 All Models
K 6.57 All Models
L 6.49 All Models
M 4.68 All Models
N 8.22 All Models
O 1.96 All Models
Dimensions
