6. Installation
Mounting Points for Body
The diagrams below are a guide for all mounting points.
Side View
Mounting point A and B need
to be tightened with slightly
angled screws to pull the
rangehood up tight to the
cabinet.
Cabinet
FRONT VIEW
TOP VIEW
BOTTOM VIEW
SIDE VIEW
SIDE VIEW
FRONT VIEW
TOP VIEW
BOTTOM VIEW
SIDE VIEW
SIDE VIEW
A
B
DANGER
Always switch o and disconnect the power supply before installing the rangehood.
Failure to do so may cause serious injury.
WARNING
Please remove lters before installation. Failure to do so may damage the clips.
