Page 18
7. Installation
Isodrive Motor Setup
EXTREMELY IMPORTANT
Please read the following instructions carefully before install. For technical
support, please contact 1300 829 066.
To remove, please pull
the white cord gently.
White Cord
Clip
Type 1: White cord
Please remove the white cord when attaching Isodrive 1600 motor (Single or Twin) system.
NOTE: DO NOT REMOVE the white cord when installing an Isodrive 650 motor (Single or Twin) system.
Type 2: A clip attached at the end of the white cord
Please remove the clip when attaching Isodrive 1600 motor (Single or Twin) system. To remove the
clip, hold down 1, 2 and 3 gently pull out to direction 4.
NOTE: DO NOT REMOVE the clip at the end of the white cord when installing an Isodrive 650 motor
(Single or Twin) system.
1
2
3
4
