SEL-787-2, -3, -4 Data Sheet Schweitzer Engineering Laboratories, Inc.
8
Figure 4 SEL-787-2E/21/2X Functional Diagram
3
3
3
1
Temperature Alarm
and Trip
SEL-787-2E/21/2X Transformer Protection Relay
52
Overcurrent
Time-Overcurrent
• Sequential Events Recorder
• Event Reports
• Web Server
• SEL, Ethernet*, Modbus RTU, Modbus TCP/IP*,
DNP3 serial*, DNP3 LAN/WAN*, FTP*, Telnet*, SNTP*,
IEEE 1588-2008 firmware-based PTP*, IEC 61850 Edition 2*,
IEC 60870-5-103*, EtherNet/IP*, PRP*, Event Messenger,
DeviceNet* Communications
• Synchrophasor Data and IEEE C37.118-2005 Compliant
Protocol
• Two Inputs and Three Outputs Standard
• I/O Expansion*--Additional Contact Inputs/Outputs, Analog
Inputs/Outputs, and RTD Inputs
• Single or Dual Ethernet Copper or Fiber-Optic
Communications Port*
8787
Overcurrent
Time-Overcurrent
Overcurrent
a
Time-Overcurrent
a
3232
2424
8181
O
U
Volts/Hertz
b
Frequency
b
LOPLOP
27P27P
5959
Restricted
Earth Fault
a
Directional
Power
b
Loss of Potential
b
Undervoltage
b
Overvoltage
b
Current
Differential
52
• Battery-Backed Clock, IRIG-B Time Synchronization
• Instantaneous, Differential, Harmonic, and RMS
Metering
• Programmable Pushbuttons and LED Indicators
• Through-Fault Monitoring
• Transformer Thermal Monitoring
• Circuit Breaker Contact Wear Monitor
• Advanced SEL
OGIC Control Equations
• 32 Programmable Display Messages
• M
IRRORED BITS Communications
• Front-Panel Programmable Tricolor LED Targets
• Front-Panel HMI With 2 x 16-Character LCD
• 5-Inch, Color, 800 x 480-Pixel Touchscreen Display*
*Optional Functions
Internal or External
RTD Input
27I27I
59I59I
Inverse-Time
Overvoltage
b
Inverse-Time
Undervoltage
b
a
Neutral and REF elements are
available in the SEL-787-21/2E models
only
b
Voltage and power elements are
available in the SEL-787-2E model only
REFREF
