Fig ure 4-2B. Typ i cal In stru ment Panel Con fig u ra tion
(He li cop ters with fuel in jected en gine - HIO-360-G1A)
Normal Procedures
Pilot's Flight Manual
1. Air speed Ind.
2. Al tim e ter
3. Low Volt age Cau tion Light
4. Fuel Low Cau tion Light
5. M/R XSMS (Temp/Press) Warn ing
Light
6. T/R XMSM Chips Cau tion Light
7. En gine & Ro tor Ta chom e ter
8. (Re served)
9. (Re served)
10. Man i fold Pres sure In di ca tor
11. Ra dio
12. Fuel Qty/Fuel Press/Cyl Head Temp
13. Oil Press/Oil Temp/Amps
14. Run ning Time Me ter
15. (Re served)
16. Panel Light Dim mer
17. Panel Light Switch
18. Po si tion Light Switch
19. Bea con Light Switch
20. Bat tery Switch
21. Trim Switch
22. Al ter na tor Switch
23. Tran sponder Cir cuit Breaker
24. Ra dio Cir cuit Breaker
25. Land ing Light Cir cuit Breaker
26. In stru ment Cir cuit Breaker
27. Clutch Cir cuit Breaker
28. Trim Cir cuit Breaker
29. Fuel Mix ture Con trol
30. Clutch Con trol Switch
31. Mag neto Key Switch
32. Fuel Shut off Con trol
33. Clutch Dis en gaged Warn ing Light
34. Hot Mic Switch
35. Fuel Pump Switch
1
3
4
5
6
7
10
2
12
13
14
35
31
32
23
27
30
29
28
33
24
25
26
11
16
34
21
17
18
19
22
20
4-10.2 Reissued: 16 Jan 2019
Reissued: 07 Dec 2012
