Fig ure 4-2A. Al ter nate In stru ment Panel Con fig u ra tion
Normal Procedures
Pilot's Flight Manual
4-10.1
1. Man i fold Pres sure In di ca tor
2. Air speed Ind.
3. Low Volt age Cau tion Light
4. Fuel Low Cau tion Light
5. M/R XSMS (Temp/Press) Warn ing
Light
6. T/R XMSM Chips Cau tion Light
7. Al tim e ter
8. Car bu re tor Heat Con trol
9. Carb Heat In di ca tor
10. Trim Switch
11. Fuel Shut off Con trol
12. Mag neto Key Switch
13. Clutch Dis en gaged Warn ing Light
14. Clutch Con trol Switch
15. Al ter na tor Switch
16. Bat tery Switch
17. Fuel Mix ture Con trol
18. Trim Cir cuit Breaker
19. Clutch Cir cuit Breaker
20. Bea con Light Switch
21. In stru ment Cir cuit Breaker
22. Po si tion Light Switch
23. Land ing Light Cir cuit Breaker
24. Ra dio Cir cuit Breaker
25. Panel Light Switch
26. Tran sponder Cir cuit Breaker
27. Hot Mic Switch
28. Panel Light Dim mer
29. Panel Light
30. Run ning Time Me ter
31. Oil Press/Oil Temp/Amps
32. Fuel Qty/Cyl Head Temp
33. En gine & Ro tor Ta chom e ter
1
2
3
4
7
6
5
8
9
11
10
23
22
21
19
18
15
20
17
16
14
13
12
26
27
25
24
33
32
31
30
29
28
SCHWEIZER
Model 269C-1 Helicopter
(He li cop ters with carbureted en gine - HO-360-C1A)
FAA Approved
Reissued: 16 Jan 2019
