Figure 7-1. Major Components
Handling, Servicing & Maint.
Schweizer RSG, LLC.
Model 269D Helicopter
Pilot's Flight Manual
Rei
ssued: 16 Jan 2019
7-13
VERTICAL STABILIZER
TAIL ROTOR TRANSMISSION
TAIL ROTOR
AFT FUSELAGE
HORIZONTAL STABILIZER
TAIL ROTOR DRIVE SHAFT
BELT DRIVE TRANSMISSION CENTER SECTION FRAME
ENGINE
LANDING GEAR
DOOR
CANOPY
MAIN ROTOR DRIVE SHAFT
MAIN ROTOR BLADE
MAIN ROTOR HUB
MAIN ROTOR CONTROL ROD
FUEL CELL
MAIN TRANSMISSION
