Schwinn 290 - Page 32

32
A Console N Seat Adjustment Handle AA Pedal, Right
B Console Mount Bracket O Seat Slider BB Shroud, Right Main
C Media Tray P Seat Rail CC 6KURXG(QJLQH5HDU
D Console Mast Q Rear Stabilizer DD Drive Belt
( Pivot Cover R Levelers (( Drive Pulley
F Data Cable, Upper S Shroud, Left Main FF Flywheel
* Insert, Lower Mast T Pedal, Left ** RPM (Speed) Sensor
H Handlebar, Upright U Crank Arm HH 6SHHG6HQVRU0DJQHW
I Handlebar Mount Cover V Stabilizer Feet II Magnet Carriage
- Seat Pad W Transport Roller -- Resistance Sensor
K Seat Frame ; Front Stabilizer KK Resistance Magnet
L Seat Back < Power Connector LL Servo Motor
M Cup Holder Z AC Adapter MM PCBA/Mount Assembly
