Before Assembly
Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a
hard,levelsurface.Allowaworkoutareaofaminimum74”x130”(1.9mx3.3m).
Basic Assembly Tips
Follow these basic points when you assemble your machine:
1. Readandunderstandthe“ImportantSafetyInstructions”beforeassembly.
2. Collect all the pieces necessary for each assembly step.
3. Using the recommended wrenches, turn the bolts and nuts to the right (clockwise) to tighten, and the left (counter-
clockwise) to loosen, unless instructed otherwise.
4. When attaching 2 pieces, lightly lift and look through the bolt holes to help insert the bolt through the holes.
5. Theassemblyrequires2people.
Note:Someaxlescontainoil.Usecautiontoavoidstainingclothesorcarpet.
SpECIFICATIONS
67.7”
(171.9 cm)
25.8” (65.6 cm)
61.5” (156.2 cm)
Maximum User Weight: 300 lbs. (136 kg)
Power Requirements:
OperationalVoltage:9VDC
Operating Current: 1500 mA
Regulatory Approvals:
ACPowerAdapter: ULlisted,CSAcertied(orequivalent),
Rated120V60HzInput,9VDC,1500mA
Output. Class 2 or LPS.
This product, its packaging, and components contain chemicals known to the State of California to cause cancer,
birth defects, or reproductive harm. This Notice is provided in accordance with California’s Proposition 65. If you
would like additional information, please refer to our website at www.nautilus.com/prop65.
