73
Right Main
Shroud
Upper Front
Shroud
Note: Crank Arm and Lower Handlebar have been
removed, but are shown here.
20. Using a #2 Phillips screwdriver, remove the 8 screws
from the Right Main Shroud.
Note: The Upper Front Shroud may need to be lifted
to access the upper screw for the Right Main
Shroud.
