79
Note: The Speed Sensor can be accessed by gently
exingtheLeftMainShroudoutwardslightly.
Note: The Shrouds have been removed from the
images to provide additional details.
Speed Sensor
Flywheel
Speed Sensor
Cable
Note: Main Shrouds removed for clarity.
Left Main
Shroud
Speed Sensor
