To reduce the risk of electrical shock or unsupervised usage of the equipment, always
unplug the power cord from the wall outlet and wait 5 minutes before cleaning, main-
taining or repairing this machine. Place the power cord in a secure location.
Note:Yourmachinemaynotmatchtheimagesprovidedexactly.ThoughtheprocedureshowstheremovalofbothUpper
Handlebars, only remove one if you are not replacing both Upper Handlebars.
1. Unplug the Power Cord from the wall outlet and machine.
2. GentlycompresstheExteriorHandlebarCoverto
releaseitfromtheInteriorHandlebarCover.Thereareve
tabs that snap to secure each Cover.
3. Using a #2 Phillips screwdriver, remove the two screws
that attach the Interior Handlebar Cover to the Handlebars.
Set the hardware safely aside for reassembly.
Exterior
Handlebar
Cover
Interior
Handlebar
Cover
Exterior
Handlebar
Cover
