Parts List
Ref. # Description Qty.
1 Frame 1
42 Handle Bar 1
3 Seat Slider Assembly with Saddle 1
A Front Stabilizer Bar with Wheels and Feet 1
B Rear Stabilizer Bar with Feet 1
51 Water Bottle Cage 2
Small Parts Box 1
Small Part Box Contents
43 Pedals with Toe Clips & Straps (Left & Right) 1 Pair
29 Pop Pin Assembly for Head Tube 1
46 13mm Hex Bolt 4
44 Flat Washer 8
45 13mm Lock Nut 4
Tools Supplied
Stamped Steel 13/14/15/17mm Combination Wrench 1
3mm Hex Wrench 1
Prior to assembly of the product, remove all components from the packaging and check them against the packaged components
list supplied above. Once you are certain that all the necessary parts have been supplied, begin with the first assembly step.
Tools Needed
3mm Hex Wrench
Stamped Steel Combination Wrench
Adjustable wrench (not included)
Grease (not included)
Assembly Manual
