20
Note: Your machine may not match the image. For reference only.
1. Loosen and remove the old Pedals.
Discard the old Pedals.
Note: The Left Pedal is reverse-threaded. Orientation is based from
a seated position on the bike. The Left Pedal has an “L”, the
Right Pedal an “R”.
Note: The following images may not match your bike exactly.
2. Apply Loctite
®
242 (or equivalent) to the pedal threads on the new
Pedal.
Disconnect the data cable from the console before you service this machine.
