EXTEND AND SECURE THE TOW BAR
❶ Place the trailer on its side with the tow bar facing up.
❷ Remove the locking pin from the tow bar bracket.
Figure 3.9
❸ Rotate the tow bar unl it rests on the front end of the
frame.
❹ Insert the locking pin through both the bracket and tow bar.
❺ Slide the metal safety loop on the end of the locking pin.
Check that it is securely in place. Figure 3.10
11 Schwinn Trailblazer Double Seat
Figure 3.10Figure 3.9
2
3
4
5
