Schwinn Trailblazer - Converting the Safety Harness for One Child

Use of the trailer without the safety strap aached to the
bicycle may result in serious injury or death. Always
aach the tow bar safety strap to the bicycle when using
the trailer.
❶ Wrap the tow bar safety strap around the bicycle frame.
Figure 4.12
❷ Clip the safety strap to the tow bar ring on the end of the
tow bar. Be sure the tow bar safety strap is securely
aached before using the trailer. Figure 4.13
21 Schwinn Trailblazer Double Seat
ATTACH THE SAFETY STRAP
Safety strap
Figure 4.12 Figure 4.13
Bicycle frame
Safety
strap
Tow bar ring
