• There are pinch points between the sidewalls and the
frame of the trailer that may cause injury
• Always fold or unfold the trailer slowly and with cauon
• Keep children clear when folding or unfolding the trailer
REMOVE THE TOW BAR FROM THE BICYCLE
❶ Remove the child from the passenger compartment
❷ Unfasten the clip on the safety strap from the tow bar
ring, and unwrap it from the bicycle frame. Clip the strap
back onto the D-ring of the tow bar. Figure 6.1
❸ Remove the locking pin from the tow bar coupler.
Figure 6.2
❹ Remove the tow bar from the coupler.
❺ Insert the locking pin through the end of the tow bar and
secure it with the safety loop.
❻ If desired, leave the coupler on the bicycle wheel hub for
future use. It is not necessary to remove when storing.
Schwinn Trailblazer Double Seat 28
6 Disassembly and Storage
Figure 6.1 Figure 6.2
5
4
3
1
2
