Schwinn Trailblazer - WARRANTY

❷ Remove the wheels by: Figure 6.4
a. Pulling the wheel release lever out and hold.
b. Remove the wheel.
c. Release the lever.
29 Schwinn Trailblazer Double Seat
2a
1
Figure 6.3
2b
Figure 6.4
Note: shown from
underside of the frame.
DISASSEMBLE THE TRAILER
❶ Remove the ag pole and separate the ag pole secons.
Figure 6.3
