5
❸ Remove the locking pin from the tow bar bracket.
Figure 6.5
❹ Fold the tow bar underneath the trailer.
❺ Place the locking pin back through the tow bar and bracket.
❻ Unfasten the three snaps on the front, back and top of the
canopy of the side walls, then unfasten the hook and loop
fasteners from the strips on the front and back of the
frame walls. Remove the canopy from the frame. Figure 6.6
Schwinn Trailblazer Double Seat 30
Note: Coupler plate will
remain assembled to
bike 99% of the me
3
Figure 6.5 Figure 6.6
4
6
