❼ Slide the tow bar into the open end of the coupler.
Important! Ensure the coupler is completely in line with
the tow bar. This reduces stress on the tow bar.
Figure 4.10
❽ Insert the locking pin into the hole on the top of the
coupler.
❾ Slide the safety loop over the end of the lock pin.
Figure 4.11
Important! Ensure the loop of the safety pin is facing away
from the wheel to prevent possible fricon against the
wheel and spokes of the bicycle.
Schwinn Trailblazer Double Seat 20
Figure 4.11Figure 4.10
