3.0 Initial Setup
|
13
11. Being careful to retain the position of the slave stage on the
table, remove the shipping bracket. Manually move top half of
the stage to access firstly the rear and then the front mounting
holes. Bolt down the slave stage firmly onto the anti-vibration
surface using M6x12 screws. Return the stage to its zero
position and replace the outer shipping bracket.
12. Two rubber membranes are supplied with the MMBP in order to
prevent the ingress of solution into the stages. Place one of
these over each of the stages, aligning the holes in the
membranes with those on the top surface of the stages.
13. Replace the top plate over the two stages and firmly bolt in
place using 12 M6x12 screws.
14. Finally, remove the shipping bracket from the slave stage.
Important: Retain the all shipping brackets for future
transit or return of the equipment. Component
damage is highly likely if these are not fitted during
shipping.
