SWIVEL SEAT ASSEMBLY CONT’D
Tools Required:
Step 3: (Bucket Seat Assembly )
a. Align the front holes of the bucket seat with the 3rd set of holes from the front of the handlebar plate,
(see diagram), then loosely screw in (Qty. 1) of item #1 into one of the front holes.
b. Align the other three holes and loosely screw in item #1 into each hole.
c. Tighten all four screws to secure the bucket seat.
1/2” Wrench or socket
Step 3a: (2-Piece Seat Assembly)
a. Align the front two holes of the seat mount plate with the 1st set of holes of the handlebar plate
(see diagram), then insert (Qty. 1) of item #1 into one of the front holes to hold the seat mount plate
in place.
b. Align the front hole of the bottom seat pad with the inserted screw and loosely screw it into the seat pad.
c. Align the other front hole of the seat pad and loosely screw in (Qty. 1) of item #1 screw.
d. Slide (Qty. 1) of item #3, then (Qty. 2) of item #4 onto each item #2 screws, then loosely screw
them into the rear two holes of the seat pad.
e. Tighten all four screws to secure the bottom seat pad and plate mount.
Item #1 (x 4)
5/16-18 x 1.25 Serrated Screw
#1
#1 #2
#3
#4
Item #1 (x 2)
5/16-18 x 1.25 Serrated Screw
Item #2 (x 2)
5/16-18 x 1 Hex Head Screw
Item #3 (x 2)
5/16 Split Washer
Item #4 (x 4)
5/16 Flat Washer
Tools Required:
1/2” Wrench or socket
Rear holes to mount Seat plate
Two front holes to mount Seat plate
Rear holes for Bucket seat
Front holes for Bucket seat
Seat Mount Plate
Bottom Seat Pad
