ASSEMBLY
SCIFIT •
S
cientific
Solutions for Fi
tness • SCIFIT •
S
cientific
Solutions for Fi
tness •
SCIFIT
8
FIXED SEAT ASSEMBLY
Step 1:
Pull upward the yellow knob of the seat adjustment lever, then lift and slide the seat post onto
the frame track making sure the roller guide rail is between the top and bottom wheels of the base.
Roller Guides
Tools Required:
1/2” Wrench or socket
Item #1 (x 4)
5/16-18 x 1.25 Serrated Screw
Step 2: (Bucket Seat Assembly)
a. Align one of the front two holes of the Bucket seat with the front set of holes on the fixed seat mount
(see diagram), then insert (Qty. 1) of item #1 into one of the seat holes and loosely tighten into place.
b. Align the second front hole of the seat and loosely tighten with (Qty. 1) item #1 screw.
d. Insert and loosely tighten the remaining two rear holes with (Qty. 2) item #1 screws.
e. Tighten all four screws to secure the seat to the fixed seat mount.
Align holes of seat with these
holes on the fixed seat mount.
Front
Rear
