116
SCION xA (EM00D0U)
Sliding Roof
The sliding roof can be operated when the ignition SW is turned to ON position.
1. Slide Open Operation
The sliding roof fully opens automatically by pressing the OPEN button of the sliding roof control SW once. The sliding roof
opens half and stops the operation once. If the sliding roof control switch is pressed again when the sliding roof is operating,
the movement of the sliding roof stops.
2. Slide Close Operation
If you keep pressing the CLOSE button of the sliding roof control SW when the sliding roof is closes.
3. Tilt Up Operation
If you press the CLOSE button of the sliding roof control SW, the sliding roof is tilted up. However, the sliding roof is not tilted
up when it is open
4. Tilt Down Operation
If you press the OPEN button when the TILT UP of the sliding roof control SW is pressed, the sliding roof is tilted down.
: Parts Location
Code See Page Code See Page Code See Page
J2 31 S13 33 S14 33
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1L
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IB1
Floor Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
Floor Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
IE1 37 Roof Wire and Floor Wire (Upper Side of the Cowl Side Panel LH)
Ground Points
Code See Page Ground Points Location
BH 38 Left Quarter Pillar
System Outline
To Next Page
