Scion 2006 xA User Manual

SCION xA (EM00D0U)
23
F
Fusible Link Block Engine Compartment Left (See Page 20)
60A MAIN (*2)
(for High Current)
120A ALT
(for High Current)
234
5
60A ABS
(for High Current)
1
60A MAIN (*1)
(for High Current)
* 1:w/ VSC
F10
F11
Black
(from Engine Wire)
* 2:w/o VSC
3
: ABS R/B Engine Compartment Right (See Page 20)
12
3
5
3
ABS CUT Relay ABS MTR Relay
5
12
