Scion 2006 xA User Manual

K CONNECTOR LIST
1234
Dark Gray
I14
1234
5678
I15
12345 76
Gray
I16
[A]
[C]
K CONNECTOR LIST
123 45
6 7 8 9 10 11 12 13
12345
13 6789101112
BA1
Black
BD2
Gray
[F]
[E]
12 34
567891011
11
43 21
5678910
AB
AABCCC
DD
DD
B
A
A
A
A
A
AAA
1
12
12
[B]
Black
J1 J4 K1 K2 L1
Dark Gray
[D]
10
SCION xA (EM00D0U)
B HOW TO USE THIS MANUAL
[A] : Indicates connector to be connected to a part. (The numeral indicates the pin No.)
[B] : Junction Connector
Indicates a connector which is connected to a short terminal.
Junction Connector
Short Terminal
Same Color
Junction connector in this manual include a short terminal which is
connected to a number of wire harnesses. Always perform
inspection with the short terminal installed. (When installing the
wire harnesses, the harnesses can be connected to any position
within the short terminal grouping. Accordingly, in other vehicles,
the same position in the short terminal may be connected to a wire
harness from a different part.)
Wire harness sharing the same short terminal grouping have the
same color.
[C] : Parts Code
The first letter of the code is taken from the first letter of part, and the numbers indicates its order in parts which
start with the same letter.
[D] : Connector Color
Connectors not indicated are milky white in color.
[E] : Indicates the connector shapes which are used to join wire harnesses.
On Left : Female connector shapes
On Right : Male connector shapes
Numbers indicate pin numbers.
[F] : Indicates connector colors. (Connectors with not indicated colors are white)
