SCION xA (EM00D0U)
123
The current is applied at all times to TERMINAL (A) 7 of the combination meter through the DOME fuse.
When the ignition SW is turned to ON position, the current flows to TERMINAL (A) 1 of the combination meter through the
GAUGE fuse. When the light control SW is turned to TAIL or HEAD position, current is applied to TERMINAL (A) 12 of the
combination meter through the TAIL fuse.
Light Reminder System
When the light control SW is in TAIL or HEAD position, the ignition SW turned to OFF from ON position, the driver’s door
opened (Door courtesy SW on), the current flows to TERMINAL (A) 1 of the combination meter stops. As a result, the
combination meter is activated and current flows from TERMINAL (A) 7 of the combination meter, the buzzer in the
combination meter goes on to remind the light is lighting up.
: Parts Location
Code See Page Code See Page Code See Page
C10 A 30 C12 30
C11 B 30 D4 32
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1A 24 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1F
To Next Page
