SCION xA (EM00D0U)
135
: Parts Location
Code See Page Code See Page Code See Page
A14 30 R2 A 31 S1 B 29
C10 A 30 R3 B 31 S16 31
C11 B 30 R9 33 S17 31
F13 32 R10 33 T4 33
F14 32 R16 C 31 T5 33
J3 31 S1 A 29
Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
2 22 Engine Room R/B (Engine Compartment Left)
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
1A 24 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
1F
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IA1 36 Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IB2 36 Floor Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
ID2 36 Engine Room Main Wire and Instrument Panel Wire (Upper Side of the Instrument Panel J/B)
IH2 37 Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
BA1 38 Rear Door LH Wire and Floor Wire (Center Pillar LH)
BB1 38 Rear Door RH Wire and Floor Wire (Center Pillar RH)
Ground Points
Code See Page Ground Points Location
IF 36 Instrument Panel Brace LH
